Magnetic Locks in Dubai - Electromagnetic Locking for Access Control Systems

A magnetic lock -also called an electromagnetic lock or maglock - uses electrical current to generate a strong magnetic force that holds a door closed. When power is applied, the electromagnet bonds to a metal armature plate on the door with a holding force of up to 1200kg, making it virtually impossible to force open while energized. When power is cut - by an authorized access credential, an emergency release, or a power failure - the door opens freely.

Magnetic locks are the standard locking device in Dubai access control systems, managed buildings, DIFC offices, hotels, and any premises requiring controlled entry and audit trail logging. Mr. Locksmith supplies and installs magnetic locks for single doors and multi-door access control systems across Dubai.

How Magnetic Locks Work

A magnetic lock consists of two components - an electromagnet mounted on the door frame and a metal armature plate mounted on the door. When energized by 12V or 24V DC power, the electromagnet holds the armature plate with a specified holding force ranging from 280kg for light interior doors to 1200kg for heavy exterior and perimeter gates.

The lock is released by cutting power - triggered by an access reader (keypad, card, fingerprint, or mobile), a push-to-exit button, a fire alarm signal, or a manual override. Magnetic locks are fail-safe —they release automatically on power failure, which meets fire safety requirements.

Types of Magnetic Locks We Supply in Dubai

Single Door Magnetic Lock (280–600kg)

For interior office doors, meeting rooms, server rooms, and storerooms. Available in surface mount and mortise configurations. The most commonly installed maglock type in commercial buildings in Dubai.

Heavy Duty Magnetic Lock (600–1200kg)

For building entrances, lobby doors, car park barriers, and perimeter gates. Higher holding force for high-traffic and high-security applications.

Shear Lock

A variant of the magnetic lock that engages in a shearing action rather than a pulling action — suitable for sliding doors, frameless glass entrances, and doors where the standard armature mount position is not possible.

Gate Magnetic Lock

Weatherproof magnetic locks rated for outdoor installation. Used on compound gates, car park barriers, and perimeter access points across Dubai villas and commercial developments.

Magnetic Lock Installation in Dubai

Magnetic lock installation requires electrical wiring, integration with an access control panel, and proper positioning of both the electromagnet and the armature plate. Mr. Locksmith provides complete magnetic lock supply and installation, including cabling, access control integration, and push-to-exit button fitting.

Our access control installation service covers the full design and installation of access control systems, including magnetic locks, card readers, keypads, and biometric readers. For single door magnetic lock replacement or repair, our team can be on-site the same day.

Need a magnetic lock installed in Dubai? Mr. Locksmith supplies and installs electromagnetic locks for offices, buildings, and access control systems. Call 055 448 3370.

‍
